Peb cov phab ntsa tag nrho -mounted tawm-daim phiaj photovoltaic zog cia qhov system muab rau tag nrho lub zog muaj peev xwm xaiv: 5KW, 10KW, 15KW, 20KW, 30KW, 40KW ib zaug-theem 220/230V AC tso zis, ib qho kev sib xyaw ua ke 2}ib zaug {1{1}{1} Kev tsim hluav taws xob tsim hluav taws xob rau cov tsev nyob deb nroog, nyob deb nroog ntawm tus kheej- ua tsev, ua liaj ua teb, villas, nkoj nuv ntses, chaw tsim kho thiab thaj chaw tsis muaj kab hluav taws xob. Txhua cov khoom siv ua tiav tau txais cov khoom tshiab Qib A 610W monocrystalline silicon hnub ci vaj huam sib luag nrog cov khoom sib thooj, ua ke nrog IP65 tsis muaj dej tsis sib txuas lub thawv, hybrid MPPT inverter tag nrho-hauv-ib lub tshuab, phab ntsa-mounted LiFePO4 lithium hlau PV 4 roj teeb, MC alloy, phos Hnub ci mounting brackets, realizing tag nrho ywj siab hnub ci tsim hluav taws xob, lub zog cia thiab AC fais fab tso zis tsis muaj hluav taws xob sib txuas.

Tag nrho cov kab ke siv 48V qis-voltage DC architecture, kev sib xyaw ua ke hybrid inverter txhawb MPPT siab tshaj plaws lub zog taug qab them nyiaj, ua- hauv ntau- theem kev tiv thaiv kev nyab xeeb; cov phab ntsa sib txuam-mounted LiFePO4 roj teeb nrog ua tau-hauv BMS tswj qhov system thiab LCD tiag- lub sijhawm tso saib lub vijtsam, lub neej voj voog ruaj khov thiab kev ua haujlwm kub zoo heev -. Lub kaw lus txhawb nqa cov khoom siv hluav taws xob ib txhij ntawm cov teeb pom kev hauv tsev, cua txias, tub yees, twj tso kua mis, cov khoom siv me me thiab lwm yam AC loads, tuaj yeem ua haujlwm tsis tu ncua txhua hnub los ntawm hnub ci zog cia. Tag nrho cov khoom dhau qhov kev ntsuas nruj nruj, IP65 sab nraum zoov plua plav pov thawj thiab tsis muaj dej tsis zoo, tsim rau ntev -ntev kev teeb tsa sab nraum zoov hauv qhov kub, nag thiab daus. Cov qauv hluav taws xob sib txawv sib txawv raws li cov qauv sib txawv ntawm cov roj teeb sib txawv, los ntawm cov tsev me me 5KW mus rau kev lag luam loj 40KW puv -load fais fab mov, kom ua tau raws li kev sib txawv ntawm-daim phiaj hluav taws xob xav tau ntawm cov xwm txheej sib txawv, txhawb nqa hla- ciam teb engineering bulk export thiab thaj chaw faib tawm - cov phiaj xwm duab.

roduct Parameter Specification ntawm Off-Grid Solar Energy Storage System

Yam khoom	5KW Tawm -Grid Solar System	10KW Tawm -Grid Solar System	15KW Tawm -Grid Solar System	20KW Tawm -Grid Solar System	30KW Tawm -Grid Solar System	40KW Tawm -Grid Solar System
Rated AC tso zis zog	5KW Ib Phase 220/230V	10KW Ib Phase 220/230V	15KW Ib Phase 220/230V	20KW Ib Phase 220/230V	30KW Ib Phase 220/230V	40KW Ib Phase 220/230V
Hnub ci vaj huam sib luag Spec	610W Mono 40.8V, 2382113430mm, 33KG / PC	610W Mono 40.8V, 2382113430mm, 33KG / PC	610W Mono 40.8V, 2382113430mm, 33KG / PC	610W Mono 40.8V, 2382113430mm, 33KG / PC	610W Mono 40.8V, 2382113430mm, 33KG / PC	610W Mono 40.8V, 2382113430mm, 33KG / PC
Vaj Huam Sib Luag Quantity	8pcs ib	16 pcs	24 pcs	32 pcs	48 pcs	64 pcs
Combiner Box 1 pcs	IP65, 2P63A DC breaker, SPD 2P20-40KA, DC500V fuse	1pc IP65, 2P63A DC breaker, SPD 2P20-40KA, DC500V fuse	1pc IP65, 2P63A DC breaker, SPD 2P20-40KA, DC500V fuse	2pcs IP65 combiner lub thawv	2pcs IP65 combiner lub thawv	4pcs IP65 combiner lub thawv
Hybrid Inverter Qauv	48V 5.5KW MPPT tag nrho -hauv-ib qho, MPPT 100A max, PV 120-500V 2pcs	48V 5.5KW MPPT tag nrho -hauv-ib 3pcs	48V 5.5KW MPPT tag nrho -hauv-ib 2pcs	48V 10KW MPPT tag nrho -hauv-ib qho, MPPT 160A max, PV 60-500V 3pcs	48V 10KW MPPT tag nrho -hauv-ib 4pcs	48V 10KW MPPT tag nrho -hauv-ib
LiFePO4 roj teeb pob	51.2V 100AH, 5.12KWH phab ntsa-mounted	51.2V 200AH, 10.24KWH phab ntsa-mounted	51.2V 300AH, 15.36KWH movable 2pcs	51.2V 200AH, tag nrho 20.48KWH phab ntsa-mounted 2pcs	51.2V 300AH, tag nrho 30.72KWH movable 4pcs	51.2V 200AH, tag nrho 40.96KWH phab ntsa-mounted
PV Cable (4mm²)	50m liab + 50m dub	100m liab + 100m dub	150m liab + 150m	dub 200m liab + 200m dub	300m liab + 300m dub	400m liab + 400m dub
MC4 Connector	8pcs ib	16 pcs	24 pcs	30 pcs	50 pcs	60 pcs
Txhawb Bracket	1set Aluminium PV mounting bracket	1set Aluminium PV mounting bracket	1set Aluminium PV mounting bracket	1set Aluminium PV mounting bracket	1set Aluminium PV mounting bracket	1set Aluminium PV mounting bracket
Outer Pack Dimension (LWH cm)	51.226.567.5	523172.5	574274	523172.5	574274	523172.5
Pob ntim (cm³)	91584	116870	177156	116870	177156	116870
Pob Pob Luj (g)	1999990	2999990	3999990	4999990	5999990	6999990
Hom kev teeb tsa	Phab ntsa-mounted tag nrho lub cev	Phab ntsa-mounted tag nrho lub cev	Phab ntsa-mounted tag nrho lub cev	Phab ntsa-mounted tag nrho lub cev	Phab ntsa-mounted tag nrho lub cev	Phab ntsa-mounted tag nrho lub cev
Output Standard	Ib theem AC 220V / 230V	Ib theem AC 220V / 230V	Ib theem AC 220V / 230V	Ib theem AC 220V / 230V	Ib theem AC 220V / 230V	Ib theem AC 220V / 230V

Khoom Feature thiab Daim Ntawv Thov ntawm Off-Grid Solar Energy Storage System

Core Product Competitive Advantages

Ua kom tiav Tag Nrho Cov Txheej Txheem Sib Koom Ua Ke, Ib qho -Stop Off-Grid PV Solution

Txhua cov khoom siv hluav taws xob qib muaj tag nrho cov ntsiab lus tseem ceeb: monocrystalline hnub ci vaj huam sib luag, IP65 combiner lub thawv, MPPT hybrid inverter, LiFePO4 lub zog cia roj teeb, PV cables, MC4 connectors thiab txhuas mounting brackets. Cov neeg siv khoom tsis tas yuav yuav cov khoom siv sib cais, ua kom tiav kev teeb tsa sib piv cov duab kos thiab phau ntawv ua haujlwm Askiv tau muab, ua kom yooj yim rau kev tsim kho engineering thiab txawv teb chaws tom qab - muag muag.

High Efficiency 610W Monocrystalline Solar Panels nrog lub zog ruaj khov

Txais cov khoom lag luam tshiab Qib A 182 monocrystalline silicon hlwb, zoo heev tsis muaj zog lub teeb teb kev ua tau zoo, ruaj khov zog tso zis rau huab, kaj ntug thiab tsaus ntuj hnub. Lub vaj huam sib luag saum npoo yog them nrog siab - transmittance tempered iav, aluminium alloy thav duab nrog anti- corrosion oxidation kev kho mob, lub neej ntev kev pab cuam sab nraum zoov, lub zog kam rau ua nyob rau hauv 0 ~ +5W kom lav lub hwj chim siab tshaj nominal tus nqi.

Txhua yam -Nyob hauv-Ib MPPT Hybrid Inverter Dual Function ntawm Them & Inverting

Integrated MPPT hnub ci charging maub los thiab AC sine yoj inverter nyob rau hauv ib chav tsev, siab tshaj MPPT nrhiav tam sim no mus txog 160A rau siab - qauv fais fab, dav PV input voltage range 60-500V, siab them efficiency. Ua-nyob rau hauv luv luv Circuit Court, overvoltage, overload, rov qab kev twb kev txuas tiv thaiv, ntshiab sine yoj AC tso zis, tshaj inductive loads xws li cua txias, twj tso kua mis dej thiab tub yees yam tsis muaj kev puas tsuaj.

Phab ntsa-Mounted LiFePO4 Roj teeb nrog Intelligent BMS Protection

Lithium hlau phosphate lub zog cia roj teeb nrog phab ntsa-mounted tsim, ib nrab siab- muaj peev xwm qauv txais yuav movable wheeled txee rau kev hloov yooj yim. Ua-hauv tag nrho BMS roj teeb tswj qhov system, tiag tiag- lub sijhawm LCD npo qhia qhov hluav taws xob, tam sim no, muaj peev xwm seem, txhawb kev sib txuas lus sib txuas lus hauv chaw taws teeb saib xyuas. Ultra- lub neej voj voog ntev, tsis tshua muaj tus kheej- paug tus nqi, zoo heev qis- qhov kub thiab txias tsis kam siv rau thaj tsam roob thiab txias.

Ntau-Qib Hwj Huam Xaiv, Kho kom haum rau Txhua Qhov Tawm-Grid Scenarios

5KW / 10KW: villa me, tsev neeg nyob deb nroog txhua hnub teeb pom kev zoo, khoom siv hluav taws xob me me hauv tsev;

15KW / 20KW: Nruab nrab ua liaj ua teb, nuv ntses nkoj, kev tsim kho lub zog ib ntus, ntau -chav tsev nyob puv load fais fab mov;

30KW / 40KW: Cov dej ua liaj ua teb loj, cov khoom siv hauv tsev ua haujlwm, lub roob hauv nruab nrab ntawm -chaw nres tsheb fais fab, kev lag luam tawm - phiajcim hluav taws xob cia.

IP65 combiner lub thawv thiab cov khoom siv tsis muaj dej tsis zoo PV tau hloov kho sab nraum zoov tag nrho - huab cua puag ncig, aluminium alloy bracket txhawb lub ru tsev, hauv av thiab phab ntsa.

Dav siv tau Scenarios

Qhov no ua tiav tawm -daim phiaj hnub ci cia yog dav siv nyob rau hauv txhua daim phiaj -tsawg zog mov scenarios:

Cov neeg nyob deb nroog Off-Grid: roob tej thaj chaw deb zos, nyob deb nroog tus kheej-ua tsev tsis muaj kab sib chaws nkag, ciam teb tus xibhwb tsev neeg ywj pheej fais fab mov

Agricultural & Pastoral Kev Lag Luam: Ua liaj ua teb irrigation dej twj tso kua mis zog, tsiaj txhu yug tsiaj ua liaj ua teb teeb pom kev zoo, tsev cog khoom ntxiv fais fab mov

Kev Tsim Kho & Kev Tsim Kho Ib Nrab: Kev loj kev tsim kho qhov chaw siv hluav taws xob ib ntus, cov cuab yeej siv hluav taws xob hauv roob hluav taws xob, kev saib xyuas lub hauv paus chaw nres tsheb fais fab

Tshwj xeeb Off-Grid Scenes: Yacht & nuv ntses nkoj fais fab mov, suab puam teeb liab chaw nres tsheb, sab nraum zoov mus pw hav zoov loj loj cia, kob ywj siab fais fab chaw nres tsheb

Kev Lag Luam Villa Projects: Hnub so villa off-grid zog cia, scenic chaw ywj siab fais fab mov, tej thaj chaw deb tsev so tag nrho photovoltaic zog tsim

Ntau cov ntsiab lus ntawm Off-Grid Solar Energy Storage System

Monocrystalline Solar Vaj Huam Sib Luag Lamination & Ncej Craft

Txhua 610W monocrystalline vaj huam sib luag tau txais EL zais qhov kev kuaj xyuas ua ntej xa khoom, siab -kub lamination nrog ob npaug EVA zaj duab xis kom tshem tawm cov npuas sab hauv. Aluminium ncej txais kev sib koom ua ke extrusion los tiv thaiv- xeb txheej, plaub- lub kaum ntse ntse tiv thaiv- qauv kev sib tsoo, sib piv MC4 cov khoom siv dej tsis sib haum kom tsis txhob DC kab luv luv sab nraum zoov.

MPPT Hybrid Inverter Circuit Aging Production

Lub inverter lub ntsiab tswj lub rooj tsavxwm dhau 72- teev tag nrho load aging test, MPPT nrhiav nti imported siab- qauv precision, tsis siv neeg txheeb xyuas lub hnub ci voltage los kho lub zog them. Tag nrho lub tshuab plhaub tau txais IP20 plua plav tsim tsim, sab hauv cov cua kub dissipation kiv cua tsis siv neeg tswj qhov kub thiab txias kom txo tau lub zog attenuation nyob rau hauv lub sijhawm ua haujlwm ntev.

LiFePO4 roj teeb BMS tiv thaiv los ua ke

LiFePO4 pawg ntawm tes nrog kev ua kom muaj peev xwm, ua tau -hauv ntau- txheej BMS tiv thaiv lub rooj tsavxwm los saib xyuas ib leeg ntawm tes hluav taws xob hauv lub sijhawm, tiv thaiv overcharge thiab tshaj - paug. Phab ntsa-mounted txee yog ua los ntawm cov tuab tuab txias dov hlau nrog anti- xeb txheej txheej, tshwj xeeb kev sib txuas xov hlau chaw nres nkoj rau kev saib xyuas keeb kwm yav dhau.

Standardized Export Ntoo Ntim & Ua ntej -Kev tshuaj xyuas kev xa khoom

Txhua qhov kev ua tiav tau txais kev ntim khoom tsis zoo ntawm cov ntoo pallet export, tag nrho cov khoom ntim nrog ua npuas ncauj hauv ob sab phlu kom tsis txhob iav vaj huam sib luag tawg, lub plhaub deformation thiab Circuit Court puas thaum lub sij hawm ntev - kev thauj mus los hauv hiav txwv. Txhua qhov teeb tsa tag nrho dhau mus tas li hnub ci them nyiaj thiab AC thauj khoom tag nrho - lub zog aging test ua ntej xa khoom, lim tawm cov khoom tsis raug nrog lub zog tsim tsis txaus, tsis ruaj khov inversion thiab roj teeb tsis ua haujlwm.

Khoom tsim nyog ntawm Off-Grid Solar Energy Storage System

Monocrystalline Hnub Ci Vaj Huam Sib Luag Hloov Efficiency & Lub Hwj Chim Kev Ntsuas Daim Ntawv Pov Thawj: 610W module fais fab tso zis daim ntawv tshaj tawm.
MPPT Hybrid Inverter Overload, Short Circuit Protection Safety Test Document: Pure sine wave AC output parameter verification.
LiFePO4 Battery Cycle Life & BMS Protection Performance Test Certificate: Ntev - lub sij hawm lub zog cia kev ruaj ntseg tsim nyog.
IP65 Combiner Box Waterproof & Surge Protection SPD Test Record: Sab nraum zoov xob laim tiv thaiv kev ua haujlwm tau ntawv pov thawj.
Daim Ntawv Qhia Tag Nrho Kev Ua Haujlwm Nruam Kev Laus: 24- teev puv-load ruaj khov tsim hluav taws xob tsim nyog rau engineering tej yaam num.

Xa, Shipping thiab pab tawm ntawm -Grid Hnub Ci Zog Cia System

01/

Packaging & Bulk Delivery

Tag nrho cov txheej txheem ntoo pallet shockproof export ntim; kev sib xyaw ua ke ntawm cov khoom siv hluav taws xob sib xyaw ua ke yog txhawb nqa rau cov neeg tsim khoom siv hluav taws xob photovoltaic thiab hla - ciam teb tshiab hluav taws xob wholesalers. Peb txhawb EXW, FOB, CIF thoob ntiaj teb kev lag luam nqe lus, ruaj khov chaw Tshuag rau 5/10/15/20/30/40KW rau lub zog qauv, ceev customized ntau lawm voj voog rau loj engineering txiav txim.

02/

Ua tiav Tom qab-Kev Pabcuam Muag Khoom rau Hla- Cov Neeg Muag Khoom

Peb muab tag nrho cov lus Askiv photovoltaic system installation drawings, engineering scene renderings, system operation manuals and cross- ciam teb cov ntaub ntawv luam rau tag nrho cov neeg lag luam wholesale. Cov khoom tseem ceeb txaus siab rau ntev - lub sijhawm lav lav; Yog tias cov neeg siv khoom tau txais cov vaj huam sib luag puas, cov khoom siv hluav taws xob tsis raug lossis cov roj teeb tsis raug tshwm sim los ntawm kev sib tsoo logistics hauv lub sijhawm lav, peb muab kev hloov pauv dawb lossis faib nyiaj raws li qhov kev puas tsuaj tiag tiag. Peb cov kws tshaj lij tshiab lub zog hluav taws xob tsim hluav taws xob cov neeg siv khoom pab teb rau txhua qhov kev nug txog kev sib piv ntawm lub zog qauv, kev thauj khoom suav, kev tsim kho, kev tsim hluav taws xob ntau thiab cov ntaub ntawv pov thawj photovoltaic xa tawm tsis pub dhau 24 teev ua haujlwm, daws txhua qhov teeb meem cuam tshuam tau zoo.

FAQ ntawm Off-Grid Solar Energy Storage System

Q1: Dab tsi yog qhov txawv ntawm cov qauv fais fab sib txawv?

A: Qhov sib txawv tseem ceeb nyob hauv qhov siab tshaj plaws AC tso zis hluav taws xob, hnub ci vaj huam sib luag kom muaj nuj nqis thiab roj teeb muaj peev xwm. Lub zog me me 5/10KW yog rau cov khoom siv hauv tsev txhua hnub; siab zog 30/40KW txhawb nqa loj inductive loads xws li cov twj tso kua mis dej thiab cua txias rau tag nrho -load nruam fais fab mov.

Q2: Cov kab ke no puas tuaj yeem ua haujlwm yam tsis muaj hnub ci teeb rau ob peb hnub sib law liag?

A: Lub pob roj teeb LiFePO4 sib tw khaws cov hluav taws xob txaus los txhawb ob peb hnub ntawm cov khoom siv hluav taws xob yooj yim hauv qab huab cua tsis tu ncua thiab los nag; Lub hnub ci txaus thaum nruab hnub tuaj yeem ua kom muaj zog ntxiv roj teeb.

Q3: Puas yog tus kws tshaj lij hluav taws xob xav tau rau kev teeb tsa?

A: Cov khoom lag luam los nrog cov lus Askiv ua tiav cov kab hluav taws xob, tab sis lub kaw lus muaj qhov siab DC voltage thiab 220V AC Circuit Court, nws raug nquahu kom nruab los ntawm cov kws tshaj lij photovoltaic electricians kom tsis txhob muaj kev nyab xeeb.

Q4: Lub kaw lus puas tuaj yeem nthuav dav tom qab kom muaj zog ntxiv?

A: Yog, MPPT inverter txhawb nqa kev nthuav dav, lub hnub ci vaj huam sib luag thiab cov roj teeb tuaj yeem ntxiv raws li kev xav tau tom qab kev loj hlob los txhim kho lub zog muaj peev xwm.
