Peb cov khoom siv 6W mini monocrystalline hnub ci vaj huam sib luag yog lub teeb yuag portable hnub ci kev daws teeb meem tshwj xeeb uas tsim los rau lub tsheb roj teeb, lub xov tooj ntawm tes, lub tsev txhab nyiaj fais fab thiab me me 12V lead-acid roj teeb, tsim nyob rau hauv Shenzhen nrog ib - xyoo lav. Lub vaj huam sib luag txais siab -kev ua tau zoo monocrystalline silicon wafers nrog txog li 20% photoelectric conversion efficiency, ruaj khov hloov lub hnub ci mus rau hauv lub zog hluav taws xob uas tsis tau tsim ua - hauv lub zog cia roj teeb, uas tuaj yeem xa tawm raws li cov khoom lag luam yam tsis muaj kev txwv tshwj xeeb roj teeb logistics. Tag nrho cov vaj huam sib luag yog laminated nrog cov epoxy resin ruaj khov nto kom ncav cuag IP65 qib dej tsis zoo, tiv thaiv lub teeb los nag thiab plua plav tawm sab nraum zoov kom ntev - siv sab nraum zoov. Standard configuration muaj xws li hnub ci vaj huam sib luag, roj teeb alligator clips, tsheb charger, 4 suction khob thiab universal lus Askiv phau ntawv qhia; peb xaiv xim xim xws li versions muaj rau kev sib piv: xiav 100A maub los, ntsuab 10A maub los thiab txiv kab ntxwv 100A maub los, txhua yam tau tshaj cov txhuas txhuas{16}}acid roj teeb kom paub txog kev tiv thaiv kev them nyiaj ntse. Lub vaj huam sib luag slim ntsuas 3001452.5mm nrog tsuas yog 120g ib lub vaj huam sib luag hnyav, ultra- lub teeb thiab yooj yim los kho ntawm lub qhov rais tsheb, RV qhov rais thiab cov tsev pheeb suab sab nraum zoov los ntawm kev sib txuam suction khob. Raws li cov qauv ntsuas (AM1.5, 1000W / ㎡ irradiance, 25 degree), nws ncav cuag 6W siab tshaj plaws lub zog tso zis, nrog dual USB thiab DC tso zis ports rau ib txhij them ntau yam khoom siv hluav taws xob me me. Qhov sib koom ua ke txheej txheej loj yog 31520058mm nrog tag nrho cov ntim hnyav 472g rau tag nrho peb cov maub los txuam qauv, compact thiab yooj yim rau hla- ciam teb khw muag khoom ntim thiab tsheb thauj mus los. Qhov zoo tshaj plaws rau lub tsheb thaum muaj xwm txheej ceev ntxiv, mus pw hav zoov sab nraum zoov them nyiaj, tawm -daim phiaj cov khoom siv hluav taws xob me me thiab cov khoom siv hluav taws xob hnub ci txhua hnub.
Khoom Parameter Specification ntawm 6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag
|
Yam khoom Specification |
Paub meej |
|
Khoom npe |
6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag Cov Khoom Siv |
|
Silicon Wafer Hom |
Monocrystalline Silicon |
|
Max zog (Pmax) |
6W |
|
Qhib Circuit Court voltage (Voc) |
12V |
|
Lub zog hluav taws xob siab tshaj plaws (Vmpp) |
18V |
|
Luv Circuit Court tam sim no (Isc) |
1A |
|
Maximum fais fab tam sim no (Impp) |
0.3A |
|
Output Ports |
USB + DC Dual tso zis |
|
Solar Cell Conversion Efficiency |
Txog li 20% |
|
Waterproof Qib |
IP65 Epoxy Laminated Nto |
|
Ib Hnub Ci Vaj Huam Sib Luag Loj |
3001452.5 hli |
|
Ib Vaj Huam Sib Luag Net Nyhav |
120g |
|
Outer Packing Dimension |
315 200 58 mm |
|
Tag Nrho Cov Txheej Txheem Ntim Qhov hnyav |
472g |
|
Keeb kwm |
Shenzhen, Suav teb |
|
Lub Sijhawm Warranty |
1 Xyoo Official Warranty |
|
Standard Accessories |
1pc Hnub Ci Vaj Huam Sib Luag, 1pc Roj Teeb Alligator Clip, 1pc Tsheb Charger, 4pcs Suction Cups, 1pc English User Manual Optional Accessory Solar Charge Controller (3 txoj kev xaiv: Xiav 100A / Ntsuab 10A / Txiv kab ntxwv 100A) Cov Lus Ceeb Toom Tshwj Xeeb Tsis muaj ua - hauv cov roj teeb cia, tuaj yeem xa tawm raws li cov khoom lag luam; phau ntawv ntsuas qhov loj me muaj qhov kam rau me ntsis |
|
Kev Xeem Xeem |
AM1.5, Irradiance 1000W / ㎡, Kub 25 degree |
Khoom Feature thiab Daim Ntawv Thov ntawm 6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag
Core Product Competitive Advantages
High Efficiency Monocrystalline Silicon Cell nrog 20% Hloov Tus Nqi
Txais yuav hwm monocrystalline silicon hnub ci wafers nrog ruaj khov 20% photoelectric conversion efficiency, deb tshaj li zoo tib yam polycrystalline panels. Nws zoo ntes lub hnub ci txawm tias nyob rau hauv lub teeb pom kev tsis muaj zog, tsis tu ncua tso hluav taws xob ruaj khov rau lub tsheb roj teeb thiab cov khoom siv digital, daws teeb meem sab nraum zoov tsis muaj hluav taws xob tsis muaj kab hluav taws xob.
01
IP65 Epoxy Laminated Waterproof & Ultra-Lub teeb Portable Tsim
Tag nrho cov vaj huam sib luag saum npoo yog ua ke nrog laminated nrog hnav- tiv thaiv epoxy resin kom ncav cuag IP65 plua plav pov thawj thiab cov qauv tsis muaj dej, muaj peev xwm tiv thaiv txhua hnub los nag txaws, plua plav thiab sab nraum zoov UV tsis muaj delamination. Lub slim ultra- lub cev nyias hnyav tsuas yog 120g, nruab nrog plaub lub khob nqus dej kom nrawm nrawm rau ntawm lub tsheb qhov rais, lub tsev pheeb suab ntaub thiab cov dav hlau sab nraum zoov, lub teeb yuag thiab yooj yim nqa mus pw hav zoov, mus ncig thiab siv tsheb.
02
Dual USB & DC Multi-Port Output, Multi-Device Compatibility
Dual tso zis tsim ntawm USB thiab DC chaw nres nkoj txhawb nqa tib lub sijhawm them cov xov tooj ntawm tes, lub tsev txhab nyiaj fais fab, tsheb dashcams, kiv cua me me thiab 12V lead-acid cia roj teeb. Ua ke nrog cov roj teeb alligator clips thiab lub tsheb charger, cov neeg siv tuaj yeem hloov pauv kev them nqi rau lub tsheb roj teeb thiab cov khoom siv digital portable, nrog kev sib raug zoo rau feem ntau cov khoom siv hluav taws xob 12V.
03
Peb xaiv Lead -Acid Battery Controllers rau Kev Tiv Thaiv Kev Txawj Ntse
Peb qhov kev hloov pauv hloov pauv yog xaiv los ua kom tau raws li qhov xav tau ntawm cov roj teeb sib txawv: xiav 100A, ntsuab 10A thiab txiv kab ntxwv 100A maub los, txhua qhov tshwj xeeb tsim los rau cov hmoov lead-acid roj teeb nrog overcharge, tshaj - paug thiab rov qab kev sib txuas tiv thaiv kev ua haujlwm, ua kom lub tsheb roj teeb muaj kev nyab xeeb thiab txhim kho kev nyab xeeb.
04
Tsis muaj teeb meem-Nyob rau hauv roj teeb, yooj yim thauj khoom & ua tiav cov khoom siv
Lub hnub ci vaj huam sib luag no tsis muaj lub zog ua- nyob rau hauv lub zog cia roj teeb, cais raws li cov khoom lag luam uas tsis muaj kev txwv tshwj xeeb txaus ntshai thauj khoom, txo kev hla - tus nqi thauj mus los thiab kev pheej hmoo ntawm kev thauj mus los. Txhua qhov ua tiav yog nruab nrog cov khoom siv txhawb nqa tag nrho suav nrog lub khob nqus dej, lub roj teeb clips thiab lub tsheb charger, tsis muaj cov khoom seem ntxiv uas xav tau rau kev siv tam sim tom qab tshem tawm, nrog rau phau ntawv qhia lus Askiv thoob ntiaj teb rau cov neeg siv sab nrauv.
05
Dav siv tau Scenarios
Qhov no portable mini solar vaj huam sib luag cov khoom siv npog tag nrho portable sab nraum zoov thiab tsheb them scenarios:
Lub tsheb fais fab xwm txheej ceev: Tsheb 12V cia roj teeb trickle charging, RV qhov rais hnub ci ntxiv zog, maus taus roj teeb tu them
Sab nraum zoov mus pw hav zoov & mus ncig ua si: Xov tooj txawb, lub tsev txhab nyiaj fais fab, Bluetooth headset sab nraum zoov thaum muaj xwm ceev them, camping me kiv cua / LED lub teeb fais fab mov
Tawm- cov khoom siv me me: ua liaj ua teb saib lub koob yees duab fais fab mov, kev tsim kho cov khoom siv me me ib ntus them, roob roob mini fais fab ntxiv
Kev siv txhua hnub portable: Balcony qhov rais hnub ci them, noj mov sab nraum zoov fais fab, yacht me me khoom siv hluav taws xob pab them
Ntau cov ntsiab lus ntawm 6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag
Monocrystalline Cell Lamination & Epoxy Waterproof Khoom siv tes ua
Txhua monocrystalline silicon cell tau soj ntsuam kev ua haujlwm ua ntej lamination kom ntseeg tau tias lub zog tsis sib xws ntawm cov khoom tiav. Cov txheej txheem ntawm tes yog tag nrho encapsulated los ntawm pob tshab epoxy resin los ntawm siab - txheej txheem txheej txheej txheej txheej txheej txheej, tshem tawm cov npuas hauv huab cua thiab cais dej vapor infiltration kom ua tiav IP65 tsis muaj dej tsis zoo. Lub ntug ntawm lub vaj huam sib luag yog polished smoothly los tiv thaiv khawb puas thaum nqa thiab installation.
Multi-Type Controller Matching & Accessory Supporting Production
Peb cov qauv xim xim (xiav 100A, ntsuab 10A, txiv kab ntxwv 100A) yog nws tus kheej tsim nrog ua - hauv kev tiv thaiv circuits rau cov hmoov lead- cov roj teeb kua qaub, nrog cov xim ntshiab kom xaiv cov neeg siv khoom yooj yim. Txhawb nqa cov khoom siv nrog rau cov kab nuv ntses, lub tsheb chargers thiab lub khob nqus tsev yog tsim nrog cov qauv loj sib xws, thiab txhua qhov khoom siv tau dhau los ntawm kev ntsuas tensile thiab ntsaws los lav lub neej kev pabcuam. Tag nrho cov khoom siv tau sib sau ua ke nrog cov ntawv Askiv ua tiav rau kev siv lag luam txawv teb chaws.
Standardized Independent Ntim & Ua ntej -Kev tshuaj xyuas kev xa khoom
Tag nrho peb tus maub los txuam versions txais kev sib koom ua ke loj txheej xim thawv nrog tag nrho cov ntim hnyav 472g, txhua lub vaj huam sib luag qhwv nrog cov yeeb yaj kiab npuas npuas hauv lub thawv kom tsis txhob epoxy nto khawb thaum lub sij hawm ntev - kev thauj mus los hauv hiav txwv thiab huab cua. Txhua lub hnub ci vaj huam sib luag tiav tau dhau los ua qhov kev ntsuam xyuas kev laus tas mus li thiab kev tshuaj ntsuam xyuas dej tsis zoo ua ntej xa zaub mov kom lim tawm cov khoom tsis raug nrog cov khoom siv tsis txaus lossis kev ua haujlwm tsis zoo.
Khoom tsim nyog ntawm 6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag
- IP65 Waterproof & Dustproof Performance Test Certificate: Txheeb xyuas kev ua haujlwm ruaj khov nyob rau sab nraum zoov txaws thiab plua plav ib puag ncig.
- Monocrystalline Silicon Cell 20% Conversion Efficiency Inspection Report: Hnub ci wafer photoelectric efficiency kuaj cov ntaub ntawv.
- Hnub Ci Vaj Huam Sib Luag Tso Tawm Tam Sim No & Voltage Stability Test Document: Standard ua hauj lwm parameter qualification raws li AM1.5 kuaj mob.
- Lead xaiv tau-Acid Controller Overcharge Protection Daim Ntawv Pov Thawj Kev Nyab Xeeb Kev Nyab Xeeb: Kev sib txuas rov qab thiab dhau- pov thawj kev tiv thaiv kev ua haujlwm.
- Epoxy Surface UV Anti-Aging Accelerated Aging Test Record: Ntev-lub sij hawm sab nraum zoov los tiv thaiv- ploj thiab tiv thaiv - cov ntaub ntawv pov thawj tawg.
Xa, Shipping thiab pab ntawm 6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag
Packaging & Bulk Delivery
Ib zaug ua tiav lub thawv ntim xim ywj pheej, cov xim sib xyaw xim cov thawv xaj xaj tau txais kev txhawb nqa rau hla - cov khw muag khoom ciam teb. Txhua lub hnub ci vaj huam sib luag yog qhwv nrog cov yeeb yaj kiab ua npuas npuas hauv cov thawv xa tawm los tiv thaiv epoxy nto khawb thiab cov khoom siv poob thaum lub sijhawm ntev - kev thauj mus los. Peb txhawb EXW, FOB thiab CIF thoob ntiaj teb cov nqe lus kev lag luam, nrog cov khoom lag luam ruaj khov rau xiav, ntsuab thiab txiv kab ntxwv peb tus maub los txuam versions.
Ua tiav Tom qab-Kev Pabcuam Muag Khoom rau Hla- Cov Neeg Muag Khoom
Peb muab lus Askiv cov khoom lag luam dawb cov lus qhia, tsheb & camping scene li kev lag luam renderings thiab khw muag khoom cov ntaub ntawv luam tawm rau txhua tus neeg lag luam wholesale. Cov khoom no txaus siab rau ib - xyoo lav lav; Yog tias cov neeg siv khoom tau txais cov panels puas lossis cov tswj tsis raug los ntawm kev sib tsoo logistics nyob rau hauv lub sijhawm lav, peb muab kev hloov pauv dawb lossis faib nyiaj raws li kev puas tsuaj tiag tiag. Peb pab neeg muab kev pabcuam ntau hom lus teb rau txhua yam lus nug txog kev xaiv tus qauv, kev teeb tsa kev lag luam, cov nqi lag luam wholesale thiab xa tawm cov ntaub ntawv xa tawm hauv 24 teev ua haujlwm, daws txhua yam khoom muaj feem xyuam nrog cov teeb meem zoo.
FAQ ntawm 6W Portable Monocrystalline Hnub Ci Vaj Huam Sib Luag
Q1: Puas yog lub hnub ci vaj huam sib luag no khaws hluav taws xob los ntawm nws tus kheej?
A: Tsis muaj cov khoom tsim ua -hauv cov roj teeb cia hauv lub vaj huam sib luag, nws tsuas yog hloov lub hnub ci mus rau qhov tiag- lub sijhawm tso hluav taws xob hluav taws xob, koj yuav tsum txuas cov roj teeb lossis cov khoom siv digital los khaws lub zog, thiab nws tuaj yeem xa tawm raws li cov khoom lag luam yam tsis muaj kev txwv roj teeb.
Q2: Dab tsi yog qhov txawv ntawm peb qhov kev xaiv tswj tau?
A: Xiav 100A thiab txiv kab ntxwv 100A maub los yog tsim rau loj - muaj peev xwm lead-acid roj teeb; ntsuab 10A maub los sib tw me me - muaj peev xwm 12V roj teeb, tag nrho nrog kev them nyiaj tiv thaiv tag nrho, sib txawv tsuas yog hauv qhov siab tshaj plaws tam sim no.
Q3: Lub vaj huam sib luag no puas tuaj yeem them cov roj teeb tsheb ib txwm nyob rau hnub huab cua?
A: Lub siab -kev ua tau zoo monocrystalline cell tuaj yeem nqus cov teeb tawg los ua hluav taws xob rau hnub huab cua, tab sis cov nqi them tam sim no yuav qis dua hnub hnub ci, tsim nyog rau kev kho qeeb qeeb ntawm cov roj teeb tsheb.
Q4: Kuv puas tuaj yeem siv nws los them cov xov tooj ntawm tes ncaj qha yam tsis muaj tus tswj hwm?
A: Yog lawm, lub vaj huam sib luag tau tsim -hauv USB tso zis chaw nres nkoj, koj tuaj yeem txuas ncaj qha rau cov xov tooj ntawm tes rau kev them nyiaj thaum muaj xwm txheej ceev yam tsis muaj tus tswj hwm; tus maub los tsuas yog ib qho kev xaiv ntxiv rau cov hlau lead-acid roj teeb tiv thaiv.
